FR-D700 Series
- Power Rating 0.4 to7.5 KW
- General-purpose Magnetic Flux Vector Control.
- High Starting Torque of 150% at 1 Hz.
- Short Time Overloading Capacity of 200% for 3s.
- Built-in Brake chopper for effective braking.
- Frequency range 0.2 to 400 Hz
- Power supply Single phase 200 to 240 VAC and Three Phase 380 to 480 VAC
- Modbus-RTU communication available as standard.
-
Enhanced features like –
- Dancer Control PID
- Power Failure Stop Function
- Traverse Function
- Regeneration Avoidance Function
- Forward/Reverse rotation prevention.
- Life Check Function.
FR-E700 Series
- Power Rating 0.4 to15 KW
- Advanced Magnetic Flux Vector Control.
- High Starting Torque of 200% at 0.5Hz.
- Short Time Overloading Capacity of 200% for 3s.
- Built-in Brake chopper for effective braking.
- USB Port for configuration and troubleshooting.
- Frequency range 0.2 to 400 Hz
- Power supply Single phase 200 to 240 VAC and Three Phase 380 to 480 VAC
- Modbus-RTU communication available as standard.
-
Enhanced features like –
- Dancer Control PID
- Power Failure Stop Function
- Traverse Function
- Regeneration Avoidance Function
- Plug-in options for communication.
- Catch spin function
FR-A800
- Power rating 0.4 to 630 KW
- Frequency Range 0 to 400 Hz
- Power supply 380 To 480 Or 500 VAC
- Torque ,Position & Real Sensor less Vector Control
- Close Loop Vector Control and easy to gain Tuning
- Compatible with CC Link, Device Net, Profibus, Ethernet & CAN open Communication
